ITEM NO:  MC-146-200CC
Specifications:
Engine type: 4-stroke,Single-Cylinder, Air-cooled,CVT
Displacement: 200cc
Compression ratio: 10.5.1
Fuel Delivery System: Fuel Pump Carburetor
Choke System: Automatic
Fuel capacity: 9.5L
Final Drive: Chain drive
Transmission: Constantly Variable Transmission
Gear Selection: Forward & Reverse Single Speed
Forward Lights: Headlights-High & Low Beam
Rear Lights: Brake Lights & Left/Right Signal lights
Starting system: Electric start
Ignition system: C.D.I
Suspension Front: Double A-arm optional
Suspension Rear: Dual Shock Swing arm
Brakes Front: Front Dual Hydraulic Disk
Brakes Rear: Rear Single Axle Hydraulic Disk
Front&Rear tire size: 21x7-10/20x10-10
Max speed: 65km/h
Max capacity:330kgs
Ground clearance: 152mm
Wheelbase: 1860mm
Vehicle size(LxWxH): 2300x1300x900mm
Trunk Size:410x852x220mm
Package: Iron cage with carton outside
Net Weight: 245kgs
Gross Weight: 320kgs
Caton Size: 2285x1290x860mm
Container: 8pcs/20ft; 16pcs/40ft; 24pcs/40HQ
