Your current location: home page - Products - UTV ITEMS

ITEM NO:  MC-160-5000W
Specifications:

1. Overall dimension(s): 2950x1430x1780mm
2. Max forward speed: 60(km/h)
3. Climbing ability: <=20 °
4. Motor: 51V,AC,5kW/ Max Power 15kW                                    Max Torque 70N.m

5. N.W:  788kgs
6. Min turning radius: 3.5m
7. carrying capacity: 340KGS
8. Running  on 1 full charge: 50+30km
9. Battery: 8V 150Ah X 9
10. Wheel base: 1910mm
11. Min.ground clearance: 220mm
12. Drive item: RWD

Motor     Suspension
Motor Type:5KW, 51V, 82AMP 102HZ
Front Suspension: Dual A-Arm 185.42mm(7.3") Travel
Electricity Consumption of Sigle Charge: 10Kwh
Rear Suspension: Dual A-Arm 185.42mm(7.3") Travel

Brakes     Tires
Front/Rear Brakes: 4-Wheel Hydraulic Disc
Front Tires: 175/65 R14 82H
Parking Brakes: Hand-Actuated
Rear Tires:  175/65 R14 82H
Function/ Dimensions/ Capacities
Wheelbase: 1905mm
Drive System: RWD
Dry Weight: 788kgs
Battery: 8V, 150Ahx9
Overall Vehicle Size: (L x W x H)2950x1375x1860mm
Overall Vehicle Load Weight: 340kgs
Min Ground Clearance: 220mm
Hitch Towing Rating: 500kgs
Cargo bed Dimensions: (L x W x H)1180×930×340mm
Cargo bed: Capacity185kgs
