40ft HQ Container 8 Units
20ft HQ Container 2 Units
Packing Size 2980*1910*1300mm
Gross Weight 980kg
Engine & Drivetrain
Cooling Liquid
Cylinders Displacement 996.6cc
Drive System
Shaft, Selectable 4x4, Front
Differential Lock
Compression Ratio 10.5 : 1
Engine Type V-twin , 4-Stroke , SOHC
Fuel System/Battery DELPHI Electronic Fuel
Injection Max Power 63kw(81hp)/6500rpm
Max Torque 95N.m/5500rpm
Transmission CVT L-H-N-R-P
Starting system Electric start
EFI ignition EPA certification Have
Dimensions
Overall Length×width×Height 3175 mm ×1950 mm
×2285mm
Cargo Box Dimensions
820 mm ×1410 mm ×250mm
Dump 35° Estimated Dry Weight 860 kg
Front/Rea Box Capacity 50kg/200kg
Fuel Capacity 30L
Wheelbase 2258 mm
Front Tread 1670 mm
Rear Tread 1590 mm
Ground clearance 340 mm
Brakes
Front/Rear Barkes
4-Wheel Hydraulic Disc with
Dual-Bore Front and Rear
Calipers Additional Spesifications
Cargo System Electric dump bed
Doors Metal Half Door
Lighting 4 D-series lights
Mirrors Rear mirror
Roof Metal Roof
Tires/Wheels
Electronic Power Steering Standard
Front Tires 29×9-14
Rear Tires 29×11-14
Wheels Cast Aluminum
Steering Rack & pinion Steering
Suspension
Front Suspension Dual A-arm
Rear Suspension Dual A-arm with Stabilizer Bar
