40ft HQ Container 6Units
Packing Size 4000*1960*1290mm
Gross Weight 1030kg
CF 1000 CC Engine
CF 1000CC ENGINE TYPE:
V-TWIN CYLINDER, LIQUID COOLED, 4-STROKE, SOHC, 8-VALVE
ENGINE DISPLACEMENT: 963 CC
FUEL SYSTEM: BOSCH® EFI
MAX POWER OUTPUT: 71 HP @ 7000 RPM
MAX TORQUE: 60 FT. LBS. @ 6500 RPM
IGNITION: ECU
STARTING: ELECTRIC
TRANSMISSION:
CVTECH® AUTOMATIC
P/R/N/H/L
Dimensions
Overall Length×width×Height 3930 mm ×1950 mm ×2285mm
Cargo Box Dimensions
820 mm ×1480mm ×390mm
Dump 25° Estimated Dry Weight 968 kg
Front/Rea Box Capacity 50kg/200kg
Fuel Capacity 30L
Wheelbase 2990 mm
Front Tread 1670 mm
Rear Tread 1590 mm
Ground clearance 350 mm
Brakes
Front/Rear Barkes 4-Wheel Hydraulic Disc with
Additional Spesifications Dual-Bore Front and Rear
Cargo System Electric dump bed
Doors Metal Half Door
Lighting 4 D-series lights
Mirrors Rear mirror
Roof Metal Roof
Tires/Wheels
Electronic Power Steering Standard
Front Tires 29×9-14
Rear Tires 29×11-14
Wheels Cast Aluminum
Steering Rack & pinion Steering
Suspension
Front Suspension Dual A-arm
Rear Suspension Dual A-arm with Stabilizer Bar
Rear Suspension Dual A-arm with Stabilizer Bar
