Your current location: home page - Products - ATV ITEMS
 |
|
ITEM NO: MC-399-1000CC Specifications: 40ft HQ Container 16 Units 20ft HQ Container 8Units
Packing Size 2320*1400*1280mm
Gross Weight 550 KGS
Technical Parameter
Engine & Drivetrain
Cooling Liquid
Cylinders Displacement 976cc
Drive System Type Selectable 2WD / 4WD / Lock 4WD with Visco-4Lok front Differential
Engine Type 4-Stroke V-Twin，SOHC
Bore*Stroke 91x75
MAX.Torgue 95NM/5500RPM
MAX.Horsepower 92HP/7300RPM
Starting system Electric
Transmission CVT shaft
Fuel System/Battery Electronic Fuel Injection
Transmission/Final Drive Automatic CVT P/R/N/L/H
Dimensions
Rack Capacity 75/150 LBS
Estimated Dry Weight 1,014 lb (460 kg)
Fuel Capacity 4.8 Gallons
Ground Clearance 13 in. (33 cm)
Overall Vehicle Size
(L x W x H) 2450*1290*1500mm
Packing Size 2320*1280*1230mm
Payload Capacity 740 lb (336 kg)
Person Capacity 2
Wheelbase 59 in. (1493 mm)
Seat Height 36.75 in. (93.3 cm)
Brakes
Front/Rear Brakes Dual 260 mm disc brakes with hydraulic twin-piston calipers
Parking Brake Park In-Transmission and Hand Brake
Additional Specifications
Front Suspension Arched double A-arm with front sway bar
Instrumentation
Digital Gauge, Speedometer, Odometer, Tripmeter, Tachometer, Coolant
Temperature, Volt Meter, Hour Meter, Service Indicator, Clock, Gear
Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light, DC Outlet
Lighting White LED Low/High & Red LED Tail / Brake Lights
Rear Suspension Torsional Trailing arm Independent (TTI)
Tires / Wheels
Electronic Power Steering Standard
Front Tires 28 x 9-14
Rear Tires 28 x 11-14
Wheels Cast Aluminum
Choose your favorite colour
Red ,Blue ,Green ,Orange ,Yellow ,white ,Black ,Grey" 40ft HQ Container 16 Units
20ft HQ Container 8Units
Packing Size 2320*1400*1280mm
Gross Weight 550 KGS
Technical Parameter
Engine & Drivetrain
Cooling Liquid
Cylinders Displacement 976cc
Drive System Type Selectable 2WD / 4WD / Lock 4WD with Visco-4Lok front Differential
Engine Type 4-Stroke V-Twin，SOHC
Bore*Stroke 91x75
MAX.Torgue 95NM/5500RPM
MAX.Horsepower 92HP/7300RPM
Starting system Electric
Transmission CVT shaft
Fuel System/Battery Electronic Fuel Injection
Transmission/Final Drive Automatic CVT P/R/N/L/H
Dimensions
Rack Capacity 75/150 LBS
Estimated Dry Weight 1,014 lb (460 kg)
Fuel Capacity 4.8 Gallons
Ground Clearance 13 in. (33 cm)
Overall Vehicle Size
(L x W x H) 2450*1290*1500mm
Packing Size 2320*1280*1230mm
Payload Capacity 740 lb (336 kg)
Person Capacity 2
Wheelbase 59 in. (1493 mm)
Seat Height 36.75 in. (93.3 cm)
Brakes
Front/Rear Brakes Dual 260 mm disc brakes with hydraulic twin-piston calipers
Parking Brake Park In-Transmission and Hand Brake
Additional Specifications
Front Suspension Arched double A-arm with front sway bar
Instrumentation
Digital Gauge, Speedometer, Odometer, Tripmeter, Tachometer, Coolant
Temperature, Volt Meter, Hour Meter, Service Indicator, Clock, Gear
Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light, DC Outlet
Lighting White LED Low/High & Red LED Tail / Brake Lights
Rear Suspension Torsional Trailing arm Independent (TTI)
Tires / Wheels
Electronic Power Steering Standard
Front Tires 28 x 9-14
Rear Tires 28 x 11-14
Wheels Cast Aluminum
Choose your favorite colour
Red ,Blue ,Green ,Orange ,Yellow ,white ,Black ,Grey"
|
|
