ITEM NO: MC-288-10000W
Specifications:
1.MOTOR:YUMA wheel hub motor 10KW powerful moto 2 controller :48V-96V 460A ,Bus current max 460A,phase current max 1200A 3 Battery:72v 120AH ,for BMS 5 Second max amp draw is 500A ,continuous amp draw is 300A the BMS settings is 210A 4. charging :84.2V 20A on board (220V input) 16A(110V input) 5. Driving :Motor direct drive at rear axle 6. suspension:F/R Double A-arm independent suspension 7. Max.Loading capacity:300KG 8. Min.ground clearance:180mm 9. Break type(F/R):F/R hydraulic disc and handle park brake 10. max speed:120km/h 11: Distance range160km-200km Chassis 12: charger time :4-7hours 13 Front wheels:185/30-R14 14. Rear wheels:295/30-R14 15. Front hanging:double arm-swing 16. product dimensions:2680x1630x770mm 17. carton dimensions: 2665x1140x730mm 18. wheelbase:1450mm 19. height of seats:19mm(seat can be removed ) 20. 20fcl:12pcs 40HQ:24pcs
|
