Your current location: home page - Products - ATV ITEMS
 |
|
ITEM NO: MC-351-200CC Specifications: Engine type : single cylinder,200cc,4-stroke,air cooled,CVT system Displacement : 200cc
Cooling : air-cooled
Max horsepower : 6.0kW/8,000r/min
Max torque: 7.0N.m/5,500r/min (N.m/r/min)
Bore*stroke : 57.4x57.8mm
Max speed :58km/h
Ignition : CDI
Starting system ; Electric start /Kick start
Battery : 12V, 9Ah
Engine oil : 0.9L
CHASSIS ETC :
Clutch :automatic clutch
Transmission : Chain
Driving wheel : Rear wheel force
Front Suspension : double a-arm
Rear Suspension :single arm
Brakes : Front: drum / Rear: disc brake
Brake operation : disc brake
Tires,front/rear :23 x 7-10 / 22 x 10-10
Weight,G.W./N.W : 90kg /108kg
Max load : 50kg
DIMENSIONS :
Wheelbase :1215mm
L*W*H : 1,870 x1010 x 1060mm
Height to seat : 760mm
Min ground clearance : 165mm
Carton size : 1540 x 810 x 750mm
Shipping info : Qty/40' HQ: 57pcs
Atv, Quad go kart and Buggy HS code:8703101100 Engine type : single cylinder,150cc,4-stroke,air cooled,CVT system
Displacement : 150cc
Cooling : air-cooled
Max horsepower : 6.0kW/8,000r/min
Max torque: 7.0N.m/5,500r/min (N.m/r/min)
Bore*stroke : 57.4x57.8mm
Max speed :58km/h
Ignition : CDI
Starting system ; Electric start /Kick start
Battery : 12V, 9Ah
Engine oil : 0.9L
CHASSIS ETC :
Clutch :automatic clutch
Transmission : Chain
Driving wheel : Rear wheel force
Front Suspension : double a-arm
Rear Suspension :single arm
Brakes : Front: drum / Rear: disc brake
Brake operation : disc brake
Tires,front/rear :23 x 7-10 / 22 x 10-10
Weight,G.W./N.W : 90kg /108kg
Max load : 50kg
DIMENSIONS :
Wheelbase :1215mm
L*W*H : 1,870 x1010 x 1060mm
Height to seat : 760mm
Min ground clearance : 165mm
Carton size : 1540 x 810 x 750mm
Shipping info : Qty/40' HQ: 57pcs
Atv, Quad go kart and Buggy HS code:8703101100
|
|
