Specifications--CFMOTO Engine
--Good performance and Steady Quality

IDENTIFICATION
Model number MC-171
Warranty 6 months
Approval EPA / EEC
ENGINE
Engine type Single-cylinder, water-cooled
Engine stroke 4-Stroke
Valve configuration SOHC
Bore*Stroke (mm/in) 87.5*82 / 3.44*3.23
Displacement (cc) 593 / 600
Compression ratio 10.2:1
Ignition type ECU
Carburetion type EFI
Maximum speed(km/h) 75 km/h
TRANSMISSION
Transmission type Automatic CVT (R/N/H/L)
Primary drive (rear wheel) Shaft
Reverse Yes
WHEEL & TIRES
Front tire  ATV 26 x 11 - 12
Rear tire  ATV 26 x 11 - 12
BRAKES
Front brake type Dual hydraulic disc
Rear brake type Dual hydraulic disc
SUSPENSION
Front suspension Independent double wishbone with preload adjustment
Rear suspension Independent double wishbone with preload adjustment
TECHNICAL SPECIFICATIONS
Product dimensions (mm/in)  2730*1460*1880 / 107.5*57.5*74
Ground clearance (mm/in) 330 / 13
Wheelbase (mm/in) 1840 / 72.4
Minimum turning radius (mm/in) 5000 / 196.9
Dry weight (kg/lbs) 640 / 1411
Fuel capacity (L/gal) 35 / 9.2
SEATS
Seat height (mm/in) 850 / 33.5
Number of seats 2
DRIVE LINE
Driveline type Selectable 4X2 / 4X4
Number of driveline modes 2
Limited slip differential Front differential
Differential lock Front differential lock
STORAGE
Front storage Yes
Rear storage Yes
Auto dump bed Yes
LIGHTS
Headlight (s) Iodine-tungsten lamp
OPTIONAL
Optional accessories —
COLOR
Standard color Red/Army green/Black/Blue
Optional color Custom made
LOADING
Packing size (mm/in) 2320*1600*1150 / 91.3*63*45.3
Quantity 20FCL : 6PCS       40HQ : 14PCS
2330X1620X1260MM

Army green/Black/Khaki:Free
Other solid color:$50
Front windshield:$120
Canvas roof:$50
Plastic roof:$100
CST 26 inch tires: $152 per set   Top light:$85
 3000lb Winch:$120
 Top cargo frame:$100
